Laser Control / QubeCL
QubeCL
QubeCL is a modular platform that provides all the tools for driving and controlling quantum cascade lasers (QCLs) at unprecedented levels of precision and simplicity.
QCLs are among the most resource-demanding devices, in terms of voltage compliance, maximum current ratings, current noise and temperature stability.
Select your QubeCL configuration and contact us for a quotation.
Specifications
Laser grounding
AnodeGND
Max current ranges
0.5, 1, 1.5, 2 [A]
RMS current noise ( 10Hz – 1MHz )
<1 μA RMS
Curret noise spectral density
<400 pA/√Hz
Current stability ( 1h )
10 ppm FS
Compliance voltage
18V
Analog modulation channels
2
Frequency range
DC – 2 MHz (-3 dB)
Gain
10 mA/V, 500μA/V
Max input signal
±10V
Digital modulation channels (optional)
2
Frequency range
250 mHz – 2 MHz (-3 dB)
Max current
±75 mA, ±2.5 mA
Laser grounding
AnodeGND, CathodeGND
Max current ranges
0.5, 1, 1.5, 2 [A]
RMS current noise ( 10Hz – 1MHz )
<1 μA RMS
Current noise spectral density
<400 pA/√Hz
Current stability ( 1h )
10 ppm FS
Compliance voltage
18V
Analog modulation channels
Number
2
Frequency range
DC – 2 MHz ( -3dB )
Gain
10 mA/V, 500 uA/V
Max input signal
±10 V
Digital modulation channels (optional)
Number
2
Frequency range
250 mHz – 2 MHz ( -3dB )
Max current
±75 mA, ±2.5 mA
Get a quote
How to order a QubeCL :
- Compose the code by choosing the modules you need.
- Insert the code in the contact form together with your request, you will receive a quote very quickly.
Connect the laser
Optional for QubeCL only, we have developed the HHL laser shield board that allows you to connect your laser in HHL package to the QubeCL.
If you wish to have an HHL laser shield board, please indicate this in your order.
Resources
QubeCL
QubeCL is a modular platform that provides all the tools for driving and controlling quantum cascade lasers (QCLs) at unprecedented levels of precision and simplicity.
QCLs are among the most resource-demanding devices, in terms of voltage compliance, maximum current ratings, current noise and temperature stability.
Select your QubeCL configuration and contact us for a quotation.
Specifications
Laser grounding
AnodeGND
Max current ranges
0.5, 1, 1.5, 2 [A]
RMS current noise ( 10Hz – 1MHz )
<1 μA RMS
Curret noise spectral density
<400 pA/√Hz
Current stability ( 1h )
10 ppm FS
Compliance voltage
18V
Analog modulation channels
2
Frequency range
DC – 2 MHz (-3 dB)
Gain
10 mA/V, 500μA/V
Max input signal
±10V
Digital modulation channels (optional)
2
Frequency range
250 mHz – 2 MHz (-3 dB)
Max current
±75 mA, ±2.5 mA
Laser grounding
AnodeGND, CathodeGND
Max current ranges
0.5, 1, 1.5, 2 [A]
RMS current noise ( 10Hz – 1MHz )
<1 μA RMS
Current noise spectral density
<400 pA/√Hz
Current stability ( 1h )
10 ppm FS
Compliance voltage
18V
Analog modulation channels
Number
2
Frequency range
DC – 2 MHz ( -3dB )
Gain
10 mA/V, 500 uA/V
Max input signal
±10 V
Digital modulation channels (optional)
Number
2
Frequency range
250 mHz – 2 MHz ( -3dB )
Max current
±75 mA, ±2.5 mA
Get a quote
How to order a QubeCL :
- Compose the code by choosing the modules you need.
- Insert the code in the contact form together with your request, you will receive a quote very quickly.
Connect the laser
Optional for QubeCL only, we have developed the HHL laser shield board that allows you to connect your laser in HHL package to the QubeCL.
If you wish to have an HHL laser shield board, please indicate this in your order.
